WHY CHOOSE THIS TIRE
Durable tread compound and robust shoulder designed for excellent wear resistance
3-groove pattern combined with zigzag grooves offering outstanding traction and water drainage
Center lug with diagonal sipes to promote traction in wet or dry conditions for the life of the tread
PRODUCT RANGE AAM31
| Size | Load index&Speed symbols | PR | Load Range | Max load and Max Air (lbs&psi) | Overall Diameter in inches | Section Width in inches | Tread Depth (in 32nds) | |||
|---|---|---|---|---|---|---|---|---|---|---|
| Dual | Single | |||||||||
| lbs | psi | lbs | psi | |||||||
| 255/70R22.5 | 140/137M | 16 | H | 5070 | 120 | 5510 | 120 | 36.54 | 10.16 | 17 |
| 11R22.5 | 146/143K | 16 | H | 6005 | 120 | 6610 | 120 | 40.09 | 11.06 | 19 |
| 11R24.5 | 149/146K | 16 | H | 6610 | 120 | 7610 | 120 | 43.06 | 11.06 | 19 |
| 315/80R22.5 | 157/154K | 20 | L | 8270 | 130 | 9090 | 130 | 42.33 | 12.6 | 19 |
